Vortech Supercharger TUNER Kit, '05-'10 6.1L 300C, Charger, Magnum, Challenger
Vortech Supercharger TUNER Kit, '05-'10 6.1L 300C, Charger, Magnum, Challenger
V-3 Si / Satin
20 Verrall Crescent
20 Verrall Crescent
Berri SA 5343
Australia
PLEASE NOTE: 6 Week Lead Time on all Vortech Supercharger Kits. Kits are Imported via Air Freight ex Manufacturer.
Product Summary
Tuner Kits are available for the 2005-2010 Chrysler/Dodge SRT8 vehicles featuring the Vortech V-3 Si-Trim centrifugal supercharger with Vortech's air-to-water dual-pass charge cooler system.
The system uses Vortech's V-3 Si-Trim supercharger. Continued development in Vortech's Lab has resulted in the V-3 Si. The "i" stands for improved and with its new patented oil control system and state of the art centrifugal compressor stage this V-3 literally blows away the competition. Industry leading 78% adiabatic efficiency [SAE J1723 standard] means less heat is being generated, drive power is reduced and more net power is produced. Less heat also means better durability.
Vortech supercharger systems are a great value. Dollar for dollar, Vortech systems deliver more horsepower than virtually any other method of upgrade. Also, driven normally, gas mileage often increases rather than decrease.
Model/Year Availability - Tuner Kits available for:
- 2005-2010 300C / Charger
- 2005-2008 Magnum
- 2008-2010 Challenger
Quality Features
- Vortech V-3 Si-Trim gear driven centrifugal supercharger features an internal lubrication reservoir that does not require a connection between the engine oil pan and the compressor gear case.
- The V-3 includes remote fluid drain hose (attached to supercharger) that allows for simple fluid changes without removing the supercharger from the vehicle
Technologically advanced, high-efficiency impeller and housing design developed in our SAE J1723 compliant supercharger test cell. Centrifugal superchargers easily make more pressure and flow than a roots type blower and are much more efficient. Read our Roots vs Centrifugal comparison to see the numbers. - Integrated dual-pass air/water charge cooler configuration features a closed loop water cooling system with a stand-alone pump, tank and front mounted heat exchanger
- High-flow bypass valve provides for surge-free compressor operation
Inlet and discharge duct connections utilize heat resistant silicon sleeves and premium quality stainless steel clamps - Billet aluminum mounting bracketry for "factory installed" appearance and rigidity
Complete bolt-on system including all necessary belts, pulleys and reusable high-flow air filter
Optional Accessories
Maxflow Race Bypass Valve Upgrade for 2005-2010 5.7/6.1L HEMI
Installation
Installation time is rated at 12-14 hours.
Installation Manual
2006-2010 6.1L Hemi Cars (Charger, Challenger, Magnum, 300C)
CARB Compliance
Tuner Kits are NOT CARB legal, and are legal in California only for racing vehicles which may never be used upon a highway (off-road use only). Installation of this part on a vehicle driven on public roads and highways is likely to violate U.S Law regarding motor vehicle emissions.
Tuner Kits and Supercharger Options
Tuner kits are the same as complete systems except without the fuel system upgrades or ECM reprogramming. This allows for custom tuning and fuel modifications that the custom tuner or racer may prefer. Vortech has supercharger options for various types of racing or boost level. For continued use, such as road racing, the V-2 series superchargers share the engine's oiling system. This approach is more suitable for continued boost conditions and allows for the addition of an oil cooler or filter. Call us for complete information on the many upgrades and options available.
