Paxton Novi 1200 Supercharger
Paxton Novi 1200 Supercharger

Paxton

Paxton Novi 1200 Supercharger

Sale price$0.00 AUD
Out of stock
SKU: 1016119

$POA

Discharge:CW Rotation - Straight
Lubrication:Oil Feed w/ Air Assist
Colour:Satin

POA - Please contact us for pricing.

Equivalent to the Vortech V-2 Si model, the NOVI 1200 with its highly advanced computer designed gears features an optimized helical profile which allows for quieter operation while providing superior performance. All NOVI 1200 units feature a 3.6:1 internal step-up ratio and are direct bolt-on replacements for Vortech V-1, V-2, or V-3 units. The supercharger uses the quieter helical cut gears (3.61:1 ratio). The NOVI 1200 Supercharger is capable of up to 775HP on modified vehicles. Extraordinary 78% peak efficiency. Ideal for latest generation of improved breathing, high-power street and strip engines.

  • Helical cut gear profile with SQ technology
  • Near silent operation
  • Available with straight or curved discharge
  • Does not include drive pulley
  • 8.75" Wide, 9.44" Tall, 5.52" Deep (not including input shaft)

Performance Specs

Internal Step-Up Ratio: 3.61:1
Max Speed: 52,000 RPM
Max Boost: 22 PSI
Max Flow: 1,150 CFM
Max Power: 775 HP
Peak Efficiency: 78%
Performance specs apply to units equipped with standard gearcase.

Dimensions

Discharge OD: 2.75"
Inlet OD: 3.5"
Discharge ID: 2.38"
Inducer Diameter: 3.1
